CAN Interface | |
Connector | 5-pin screwed terminal block (CAN_GND, CAN_L, CAN_SHLD, CAN_H, CAN_V+) |
Baud Rate (bps) | 10 k, 20 k, 50 k, 125 k, 250 k, 500 k, 800 k, 1 M |
Terminator Resistor | Switch for 120 Ω terminator resistor |
Node ID | 1~99 selected by rotary switch |
Protocol | CCON ver2.00 |
Digital Input | |
Channels | 16 (Sink/Source) |
ON Voltage Level | +3.5~+30VDC |
OFF Voltage Level | +1VDC Max. |
Input Impedance | 3kΩ 0.3W |
Intra-module Isolation | 3750Vrrns |
ESD Protection | 4kV contact for each channel |
Reaction Time | 200 us |
LED | |
Round LED | PWR LED, RUN LED, ERR LED |
Terminal Resister | 1 LED as terminal resister indicators |
DI LED | 16 LEDs as digital input indicators |
Power | |
Input range | Unregulated +10 ~ +30 VDC |
Power Consumption | 1.5 W |
Mechanism | |
Installation | DIN-Rail |
Dimensions | 32.3 mm x 99 mm x 77.5 mm (W x L x H) Detail |
Environment | |
Operating Temp. | -25 ~ +75 ℃ |
Storage Temp. | -30 ~ +80 ℃ |
Humidity | 10 ~ 90% RH, non-condensing |
