LP-5131-OD PAC with Linux kernel 2.6.19 and one LAN port and Audio

Thương hiệu: ICP DAS | Tình trạng: Còn hàng

Liên hệ

PXA270, 520 MHz CPU
Linux kernel 2.6.19 Inside
Embedded Service: Web Server, FTP Server, Telnet Server, SSH Server
64 MB Flash, 128 MB SDRAM
Built-in Ethernet, USB, RS-232, RS-485

THÔNG TIN SẢN PHẨM

LP-5131-OD PAC with Linux kernel 2.6.19 and one LAN port and Audio

Models	LP-5131	LP-5131-OD	LP-5141	LP-5141-OD
System Software
OS	Linux kernel 2.6.19
Embedded Service	Web Server, FTP Server, Telnet Server, SSH Server
SDK Provided	Standard LinPAC SDK for Windows and Linux by GNU C language
CPU Module
CPU	PXA270, 520 MHz
SDRAM	128 MB
NVRAM	31 Byte (Battery backup, data valid up to 10 years)
Flash	64 MB
EEPROM	16 KB
Expansion Flash Memory	microSD socket with one 2 GB microSD card (support up to 32 GB microSDHC card)
RTC (Real Time Clock)	Provide second, minute, hour, date, day of week, month, year
64-bit Hardware Serial Number	Yes, for Software Copy Protection
Dual Watchdog Timer	Yes
LED indicator	3 Dual-Color LEDs (PWR, RUN, L1 ~ L4; RUN, L1 ~ L4 for user programmable)
Rotary Switch	Yes (0 ~ 9)
VGA & Communication Ports
VGA	Yes 640 × 480/800 × 600
Ethernet	RJ-45 x 1, 10/100 Base-TX (Auto-negotiating, Auto MDI/MDI-X, LED indicators)		RJ-45 x 2, 10/100 Base-TX (Auto-negotiating, Auto MDI/MDI-X, LED indicators)
USB 1.1 (host)	2		1
Audio Port (Microphone-In and Earphone-Out)	-	Yes	-	Yes
COM 1	RS-232 (RxD, TxD and GND); Non-isolated
COM 2	RS-485 (Data+, Data-); 2500 VDC isolated
COM 3	RS-232 (RxD, TxD and GND); Non-isolated
I/O Expansion
I/O expansion bus	I/O expansion board optional
Mechanical
Dimensions (W x L x H)	91 mm x 132 mm x 52 mm
Installation	DIN-Rail
Environmental
Operating Temperature	-25 °C ~ +75 °C
Storage Temperature	-30 °C ~ +80 °C
Ambient Relative Humidity	10 ~ 90% RH (non-condensing)
Power
Input Range	+10 VDC ~ +30 VDC
Isolation	1 kV
Consumption	4.8 W	6 W	4.8 W	6 W
