Module 1 cổng CAN ICP DAS I-87120-G CR

Thương hiệu: ICP DAS | Tình trạng: Còn hàng

Liên hệ

1-port CAN Programmable I-87K Module

THÔNG TIN SẢN PHẨM

I-87120-G CR: Module 1 cổng CAN cho bộ lập trình nhúng PAC

Features

Common Features:

One CAN port expansion for I-8000, iP-8000, ViewPAC-2000, WinPAC-8000, LinPAC-8000 and XPAC-8000-CE6
4096 records CAN message receive-buffer size
4096 records buffer size for the command from I-8000/ iP-8000/ ViewPAC-2000/ WinPAC-8000/ LinPAC-8000/ XPAC-8000-CE6 to I-87120
Provide C/C++ function libraries to send and receive CAN messages
Demos and utility are provided
3 indication LEDs (Rx, Tx and Err LEDs)

CAN Port Features:

Support user-defined baud
2500 Vrms isolation
Baud : 5Kbps, 10Kbps, 20Kbps, 25Kbps, 50Kbps, 100Kbps, 125Kbps, 200Kbps, 250Kbps, 500Kbps, 800Kbps, 1Mbps

Software Utility Features

Development Toolkit for I-8000/WinCon/LinCon/WinPAC
I-87120 don't support any ISaGRAF series main control unit

Introduction

CAN (Controller Area Network) is a serial bus control protocol especially suited to constrnct intelligent industry devices networks and build smart automatic control systems. It is popularly applied in the industrial automation, building automation, vehicle, marine, and embedded control network. In order to expand the CAN functions of ICPDAS products, I-87120 module is developed for this purpose. It is a kind of module, and need to be plugged into a host unit, such as I-8000 and iP-8000 series MCU (Main Control Unit), ViewPAC-2000, WinPAC-8000, LinPAC-8000 and XPAC-8000-CE6. I-87120 give a way to connect these ICPDAS host unit with CAN network. Owing to the features of I-8000, iP-8000, ViewPAC-2000, WinPAC-8000, LinPAC-8000 and XPAC-8000-CE6, these host units can be arranged to be a CAN converter, CAN slave device and CAN master device in a CAN network. The righr-hand-side figure shows the application architecture for I-87120 modules.

Applications

• DeviceNet, CANopen, CAN J1939, SDS (System Wide Network) protocol application
• CAN bus communication application
• Industry automation
• Industrial Machinery
• Building Automation
• Food & Beverage
• Semiconductor Fabrication
• Control system

Specifications

Software
Driver	For I-8000/ iP-8000/ ViewPAC-2000/ WinPAC-8000/ LinPAC-8000/ XPAC-8000-CE6
Library	TC/BC, GCC, VB.Net 2003, C#.Net 2003, VB.Net 2005, C#.Net 2005, eVC++ 4.0

CPU Module
CPU	80186, 80 MHz or compatible
EEPROM	2 KB
Flash	512 KB
SRAM	512 KB
Real Time Clock	Yes

LED Indicators
Status	1 x Power 1 x CAN status 1 x Operating mode

CAN
Controller	NXP SJA1000T with 16 MHz clock
Transceiver	NXP 82C250
Ports	1
Baud Rate	10 k ~ 1 M bps
Isolation	3000 VDC for DC-to-DC, 2500 Vrms for photo-couple
Terminal Resistor	Jumper for 120 Ω terminal resistor
Specification	ISO-11898-2, CAN 2.0A and CAN 2.0B

Power
Consumption	2 W

Mechanical
Dimensions (mm)	31 x 91 x 115 (W x L x H)

Environmental
Operating Temperature	-25 ~ +7 5 °C
Storage Temperature	-30 ~ +80 °C
Humidity	10 ~ 90% RH, Non-condensing

Download

Data sheet

Documents

Ordering information

I-87120-G

1-port Programmable CAN Module (Serial Bus Type) (RoHS)
