Module 4 đầu vào số + 4 đầu ra Relay Kinco K623-08DR

Thương hiệu: Kinco | Tình trạng: Còn hàng

Liên hệ

DC24V Input 4 pts, Relay Output 4 pts

Tính năng

Thông số kỹ thuật

Input point	4, totally classified into 1 groups
Input type	Source (common-cathode)/ sink (common-anode)
Input Voltage	Rated DC24V, voltage range of logic "1" is DC 11~30V
Output point	4, totally classified into 1 groups
Output type	Relay
Load voltage	Max. DC30V/AC250V, max.load current of each channel is 2A
Isolation mode	Di channels adopt opto-coupler isolation DO channels adopt relay isolation
Signal Indication	Separated LED indicates for each channel
Module width	50mm

Name	Order no.	Specification
PM621	K621-08DX	DI 8*DC24V
PM621	K621-16DX	DI 16*DC24V
PM622	K622-08XR	DO 8 * relay
	K622-16XR	DO 16 * relay
	K622-08DT	DO 8*DC24V
	K622-16DT	DO 16*DC24V
PM623	K623-16DR	DI 8 * DC24V, DO 8 * relay
	K623-08DR	DI 4 * DC24V, DO 4 * relay
	K623-16DT	DI 8DC24V，DO 8DC24V
	K623-08DT	DI 4DC24V, DO 4DC24V
PM631	K631-04IV	4-channel AI, 4-20mA/1-5V/0-20mA/0-10V
	K631-04RD	4 channels RTD Input，Pt100, Pt1000, Cu50, Resistance
	K631-04TC	4-channel thermocouple input. J type, K type, E type, S type, internal/external compensation selectable
PM632	K632-02IV	2-channel AO, 4-20mA/1-5V/0-20mA/0-10V
PM633	K633-04IV	2-channel AI, 4-20 mA / 1-5V / 0-20 mA / 0-10V 2-channel AO, 4-20 mA / 1-5V / 0-20 mA / 0-10V
PS680	K680	Input voltage of the extended power supply module: AC85~265V; Output rated current: 5V 1A / 24V 250mA

Thông tin đặt hàng

DC24V Input 4 pts, Relay Output 4 pts

Tài liệu

Catalog
