Module 4 đầu vào nhiệt độ TC Kinco K631-04TC

Thương hiệu: Kinco | Tình trạng: Còn hàng

Liên hệ

4 channels thermocouple Input (J type, K type, E type, S type)

Tính năng

Thông số kỹ thuật

Input channel	4
Input signal	J type, K type, E type, S type, internal/external compensation selectable
Measurement accuracy	0.1%F.S
Parameter configuration	Independent parameter configuration can be made for each channel by KincoBuilder software
Measurement range	J type -210~1200℃, K type -270~1300℃, E type -120~1000℃, S type -50~1600℃
Error indication	Red LED of each channel indicates input signal exceeds measurement range
Module width	50mm

Name	Order no.	Specification
PM621	K621-08DX	DI 8*DC24V
PM621	K621-16DX	DI 16*DC24V
PM622	K622-08XR	DO 8 * relay
	K622-16XR	DO 16 * relay
	K622-08DT	DO 8*DC24V
	K622-16DT	DO 16*DC24V
PM623	K623-16DR	DI 8 * DC24V, DO 8 * relay
	K623-08DR	DI 4 * DC24V, DO 4 * relay
	K623-16DT	DI 8DC24V，DO 8DC24V
	K623-08DT	DI 4DC24V, DO 4DC24V
PM631	K631-04IV	4-channel AI, 4-20mA/1-5V/0-20mA/0-10V
	K631-04RD	4 channels RTD Input，Pt100, Pt1000, Cu50, Resistance
	K631-04TC	4-channel thermocouple input. J type, K type, E type, S type, internal/external compensation selectable
PM632	K632-02IV	2-channel AO, 4-20mA/1-5V/0-20mA/0-10V
PM633	K633-04IV	2-channel AI, 4-20 mA / 1-5V / 0-20 mA / 0-10V 2-channel AO, 4-20 mA / 1-5V / 0-20 mA / 0-10V
PS680	K680	Input voltage of the extended power supply module: AC85~265V; Output rated current: 5V 1A / 24V 250mA

Thông tin đặt hàng

4 channels thermocouple Input (J type, K type, E type, S type)

Tài liệu

Catalog
