Module 2 đầu ra + 2 đầu vào tương tự Kinco K633-04IV

Thương hiệu: Kinco | Tình trạng: Còn hàng

Liên hệ

2-channel AO + 2-channel AI, 4-20mA/1-5V/0-20mA/0-10V

Tính năng

Thông số kỹ thuật

Input channel	2, 4-20mA, 1-5V, 0-20mA, 0-10V signals are optional
Measurement accuracy	0.3%F.S
Output channel	2, 4-20mA, 1-5V, 0-20mA, 0-10V signals are optional
Output accuracy	0.3%F.S
Parameter configuration	Parameters of each channel can be configured by Kincobuilder software separately
Signal limitation	Input current of each channel shall not exceed 24mA, input voltage shall not exceed 12V. The value of output channel is not allowed to exceed chosen range
Error indication	Red LED of each channel indicates input signal exceeds measurement range
Module width	50mm

Name	Order no.	Specification
PM621	K621-08DX	DI 8*DC24V
PM621	K621-16DX	DI 16*DC24V
PM622	K622-08XR	DO 8 * relay
	K622-16XR	DO 16 * relay
	K622-08DT	DO 8*DC24V
	K622-16DT	DO 16*DC24V
PM623	K623-16DR	DI 8 * DC24V, DO 8 * relay
	K623-08DR	DI 4 * DC24V, DO 4 * relay
	K623-16DT	DI 8DC24V，DO 8DC24V
	K623-08DT	DI 4DC24V, DO 4DC24V
PM631	K631-04IV	4-channel AI, 4-20mA/1-5V/0-20mA/0-10V
	K631-04RD	4 channels RTD Input，Pt100, Pt1000, Cu50, Resistance
	K631-04TC	4-channel thermocouple input. J type, K type, E type, S type, internal/external compensation selectable
PM632	K632-02IV	2-channel AO, 4-20mA/1-5V/0-20mA/0-10V
PM633	K633-04IV	2-channel AI, 4-20 mA / 1-5V / 0-20 mA / 0-10V 2-channel AO, 4-20 mA / 1-5V / 0-20 mA / 0-10V
PS680	K680	Input voltage of the extended power supply module: AC85~265V; Output rated current: 5V 1A / 24V 250mA

Thông tin đặt hàng

2-channel AO + 2-channel AI, 4-20mA/1-5V/0-20mA/0-10V

Tài liệu

Catalog
