Miễn phí vận chuyển với đơn hàng từ 10.000.000đModule 2 cổng PoE Ethernet Modbus TCP 16 kênh đầu ra số DO ICP DAS PET-7245 CR
Features
Introduction
The PET-7245 provides 16 source-type digital output channels. It features optical isolation for 3750 VDC of transient overvoltage protection and doesn’t have channel-to-channel isolation. The power-on value and safe value of digital output channelare programmable. In some industrial applications, the user can connect the output channel of PET-7245 to the RM series relay module to switch inductive loads.
Specification
| CPU Module | |
|---|---|
| Watchdog Timer | Yes, Module (0.8 second), Communication (Programmable) |
| EMS Protection | |
|---|---|
| EFT (IEC 61000-4-4) | ±4 kV for Power Line |
| ESD (IEC 61000-4-2) | ±4 kV Contact for Each Terminal ±8 kV Air for Random Point |
| Surge (IEC 61000-4-5) | ±2 kV for Power Line |
| LED Indicators | |
|---|---|
| Status | 1 x Power, 2 x Ethernet, 16 x I/O, 1 x PoE |
| Software | |
|---|---|
| Built-in Web Server | Yes |
| Digital Output | |
|---|---|
| Channels | 16 |
| Type | Isolated Open Source |
| Sink/Source (NPN/PNP) | Source |
| Load Voltage | +10 VDC ~ +40 VDC |
| Max. Load Current | 600 mA/channel |
| Overvoltage Protection | 47 VDC |
| Overload Protection | 1.4 A (with short-circuit protection) |
| Short-Circuit Protection | Yes |
| Power on Value | Yes, Programmable |
| Safe Value | Yes, Programmable |
| Ethernet | |
|---|---|
| Ports | 2 x RJ-45, 10/100 Base-TX, Swtich Ports |
| PoE | Yes |
| Security | ID, Password and IP Filter |
| Protocol | Modbus/TCP, Modbus/UDP |
| Power | |
|---|---|
| Reverse Polarity Protection | Yes |
| Consumption | 3.1 W |
| Powered from PoE | Yes, IEEE 802.3af, Class1 |
| Powered from Terminal Block | 12 ~ 48 VDC |
| Mechanical | |
|---|---|
| Dimensions (mm) | 76 mm x 120 mm x 38 mm (W x L x H) |
| Installation | DIN-Rail or Wall mounting |
| Environmental | |
|---|---|
| Operating Temperature | -25 ~ +75°C |
| Storage Temperature | -30 ~ +80°C |
| Humidity | 10 ~ 90% RH, Non-condensing |
Download
Ordering information
| PET-7245 CR | PoE Ethernet I/O Module with 2-port Ethernet Switch and 16-ch DO (RoHS) |
