Card PCI High-speed 2-axis Motion Control Card with FRnet Master ICP DAS PISO-PS200 CR

Thương hiệu: ICP DAS | Tình trạng: Còn hàng

Liên hệ

PCI Bus, High-speed 2-axis Motion Control Card with FRnet Master

THÔNG TIN SẢN PHẨM

Features

• Independent 2-axis motion control
• Support for hand wheel and jog functions
• 2-axis linear / 2-axis circular interpolation function
• Continuous interpolation function
• Programmable T/S-curve acceleration and deceleration
• A maximum of 4 MHz pulse output rate for each axis
• Pulse output types: CW/CCW or PULSE/DIR
• 32-bit encoder counter for each axis
• Encoder pulse input types: A/B phase or Up/Down
• Programmable automatic homing for each axis
• Programmable software limits
• Expandable Remote I/O: 128 DI & 128 DO via a two-wire FRnet interface

Introduction

The PISO-PS200 is a 2-axis stepping/pulse-type servo motor control card that can be used on any IPC with a 5 V PCI bus, and is suitable for general-purpose motion control applications. This card equipped with one FRnet Master which allows the fast remote I/O of the IPC to be expanded easily. The two-wired FRnet interface allows a maximum 128 DI and 128 DO channels, which are automatically scanned within a period of 2.88 ms. In addition to its wide speed range, this intelligent motion controller also has a variety of motion control functions built in, such as 2-axis linear interpolation, 2-axis circular interpolation, T/S-curve acceleration/deceleration, numerous synchronous actions, automatic homing, and others. A major advantage is that the majority of the PISO-PS200 motion control functions are performed by the high-performance motion ASIC with little load on the processor. The motion status, FRnet I/O, and the other I/O cards on the IPC can still be monitored while driving the motors. As the low CPU loading requirements of the PISO-PS200 is minimal, one or more motion cards can be used with a single IPC. ICP DAS also provides a variety of functions and examples that can be used to reduce the need for additional programming, making it a highly cost-effective solution for motion control application developers.

Specification

Software
OS Support	Windows 7/10 32/64-bit Windows XP/2000 32-bit
Utility	EzGo Utility

Hardware
Connector	37-pin D-Sub

General
Speed Profile	T/S-curve
Position Control Mode	Incremental mode
Operation Mode	Semi-closed Loop
No. of Axes	2
Command Type	Pulse command

Axis I/O
Servo Interface Output	SVON
Mechanical Switch Input	Home, LMT+/-, NHOME, EMG
Servo Interface Input	INP, ALM

Encoder Input
Ring Counter Mode	32-bit
Mode	A/B pulse, Up/Down
Counting Rate	4 MHz (Max.)
Counter Width	32-bit

Pulse Output
Counter Width	32-bit
Mode	CW/CCW, PULSE/DIR
Rate	4 MHz (Max.)

Interpolation
Cicular	2 axes
Linear	2 axes

Digital Input
Channels	Local: 2 DI Expandable: 128 DI
Isolation	(with DN-8237) 2500 Vrms optical isolation

Digital Output
Channels	Local: 2 DO Expandable: 128 DO
Isolation	(with DN-8237) 2500 Vrms optical isolation

PC Bus
Type	5 V PCI bus

Power
Consumption	+5 V @ 500 mA

Environmental
Operating Temperature	-20 ~ +75°C
Storage Temperature	-30 ~ +85°C
Humidity	5 ~ 85% RH, non-condensing

Download

Data sheet

D ocuments

Odering information

PISO-PS200

PCI Bus, High-speed 2-axis Motion Control Card with FRnet Master
