Module PoE Ethernet Modbus TCP 8 kênh AI + 4 kênh DI + 4 kênh DO ICP DAS PET-7H16M CR

Thương hiệu: ICP DAS | Tình trạng: Còn hàng

Liên hệ

PoE Ethernet High Speed Data Acquisition Module with 8-ch 16-bit Simultaneously Sampled AI, 4-ch DI, 4-ch DO

THÔNG TIN SẢN PHẨM

Tính năng

8 Single-ended Analog Input Channels (16-bit Resolution)
16-bit ADC with Built-in Anti-aliasing Filter
Supports Real Sample and Hold
Sample Rate up to 200 kS/s
4 x DO and 4 x DI Channels
1 x High-Speed Counter and 4 x Low-Speed Counters (32-bit)
Continuous and N Data Sample Data Transmission Mode
A/D Trigger Mode
1. Software Trigger
2. External Digital Signal Event Trigger
3. Pre-Trigger/Post-Trigger/Delay-Trigger
4. Analog Threshold Trigger
5. External Clock Signal Synchronization A/D Acquisition
Software Support
1. Supported Operating Systems
  Windows 7/8/10 and Linux
2. Software Compatibility
  1. Microsoft VC, C#, VB.NET SDK API and Demo
  2. NI LabVIEW Toolkit and Demo for Windows
  3. • C/C++ library and Demo for Linux
Built-In 10/100BASE-T Auto-negotiating, Auto MDI/MDI-X Ethernet Port
Option for External Power Supply or POE Supply

Giới thiệu

The PET-7H16M is an high speed data acquisition devices built-in a Ethernet communication port for data transfer over the network and it includes eight high speed 16-bit single-ended analog inputs (200 KHz sample and hold for 8 channels), 4-channel digital inputs and 4-channel digital outputs. It provides programmable input range on all analog channels (±5 V and ±10 V), digital output can be set output with Short-circuit protection and overload protection. The counter value of 4-channel Low-speed DI counters and 1-channel High-speed counter are latched by ADC sampling time synchronously.

PET-7H16M also has qualification for 4 kV ESD protection as well as 2500 VDC intra module isolation. In addition, the 16-bit ADC includes built-in anti-aliasing filtering to adjust the appropriate sampling rate and filter out modulator and signal noise. The PET-7H16M is not only suitable for a wide range of mobile/portable measurement applications, but also for precision signal measurement.

Ứng dụng

High Speed Acquisition via Ethernet
Temperature, Vibration, Strain High Speed Measurement Application
High Voltage and High Current High Speed Measurement Application

Thông số kỹ thuật

Software
OS	Windows 7/8/10 and Linux
Protocol	TCP Streaming (Access data by SDK library) Modbus TCP
Utility	Configuration, graphically display and data logging
SDK	Windows 。Microsoft VC, C#, VB.NET SDK API and Demo 。Python Demo 。NI LabVIEW Toolkit and Demo Linux 。C/C++ library and Demo 。.NET library and Demo 。Python Demo

EMS Protection
EFT (IEC 61000-4-4)	± 4 kV for power
ESD (IEC 61000-4-2)	±4 kV contact for each terminal , ±8 kV air for random point

LED Indicators
Status	1 x System, 1 x Ethernet, 1 x PoE

External Clock/Digital Trigger
Counter	32 bits Max. Count, 30 kHz Max. Input Frequency
Trigger Type	Falling edge
Trigger Pulse Width	1.5 µs Min.
ON Voltage Level	+5 ~ 5.5 VDC @ 15 mA
OFF Voltage Level	< 0.8 VDC

Analog Input
Channels	8 Single-ended (Simultaneously)
Range	Bipolar Input (Programmable): ± 10 V, ± 5 V
Resolution	16-bit
Accuracy	0.05 % of FSR
Sampling Rate	200 kS/s (Each channel)
FIFO Size	2 k samples
Trigger Mode	Programmable: Software/External clock trigger/Digital trigger (Post-trigger/Pre-trigger/Delay-trigger), Analog threshold trigger
Synchronous Input	Yes

Digital Input
Channels	4
Type	Wet Contact
Sink/Source (NPN/PNP)	Sink/Source
ON Voltage Level	+5 ~ +30 VDC
OFF Voltage Level	1 VDC Max.
Isolation	2500 VDC

Digital Input/Counter
Channels	4
Max. Counts	32-bit
Frequency	1 kHz Max.

Digital Output
Channels	4
Type	Isolated Open Collector
Sink/Source (NPN/PNP)	Sink
Load Voltage	+5 ~ 30 VDC
Load Current	100 mA
Overload Protection	1.3 A
Short-circuit Protection	Yes
Isolation	2500 VDC

Ethernet
Ports	1 x RJ-45, 10/100 Base-TX (Auto-negotiating, Auto MDI/MDI-X)
PoE	Yes, IEEE 802.3af, Class 2
Security	ID, Password and IP Filter
Protocol	Modbus TCP Slave, Private TCP Raw Data

Power
Reverse Polarity Protection	Yes
Consumption	2.6 W (Max.)
Powered from Terminal Block	+12 ~ 48 VDC

Mechanical
Casing	Metal
Dimensions (mm)	76 x 120 x 38 (W x L x H)
Installation	DIN-Rail, Wall mounting

Environment
Operating Temperature	-25 ~ +75 °C
Storage Temperature	-30 ~ +80 °C
Humidity	10 ~ 90% RH, Non-condensing

Download

Data sheet

Documents

Thông tin mua hàng

PET-7H16M CR

PoE Ethernet High Speed Data Acquisition Module with 8-ch 16-bit Simultaneously Sampled AI, 4-ch DI, 4-ch DO (RoHS)
