Card PCI Express 64 kênh đầu vào số DI ICP DAS PEX-P64 CR

Thương hiệu: ICP DAS | Tình trạng: Còn hàng

Liên hệ

PCI Express, 64-ch Isolated DI Board

THÔNG TIN SẢN PHẨM

Features

Support PCI Express x1
Card ID Function(SMD Switch)
64-channel optically isolated digital input
Built-in DC/DC converter providing 3000 VDC isolation
Four isolated banks when using four isolated external power supplies
3750 Vrms photo-isolation protection
Selectable internal or external power for DI

Introduction

The PEX-P64 series supports PCI Express bus. These cards provide 64 optically isolated digital input (DI) channels that use either an internal or external power supply that can be selected via a jumper. The internal power is provided by an onboard isolated DC/DC converter that provides 3000 VDC isolation and is used for connecting dry-contact input devices. These DI channels are arranged into four isolated banks when using four isolated external power supplies. DI channels 0 ~ 15 are allocated to bank A, DI channels 16 ~ 31 are allocated to bank B, DI channels 32 ~ 47 are allocated to bank C, and DI channels 48 ~ 63 are allocated to bank D. The onboard photo couplers provide 3750 Vrms isolation, and act as an interface to field logic signals, eliminate ground-loop problems, and isolate the host computer from damaging voltages. These cards contains has a single DB-37 connector and a single 40-pin male header, each of which contains 32 input channels.

The PEX-P64 series also adds a Card ID switch on-board. Users can set Card ID and then recognize the board by the ID via software when using two or more PEX-P64 series cards in one computer.

The cards support various OS versions, such as Linux, DOS, Windows. DLL and Active X control together with various language sample program based on Turbo C++, Borland C++, Microsoft C++, Visual C++, Borland Delphi, Borland C++ Builder, Visual Basic, C#.NET, Visual Basic.NET and LabVIEW are provided in order to help users to quickly and easily develop their own applications.

Accessories

Specification

Hardware
Card ID	Yes (4-bit)
Connector	Female DB37 x 1 40-pin Box header x 1

Digital Input
Channels	64
Type	Photocoupler (Sink and Source)
Response Speed	4 kHz (Typical)
Trigger Mode	Static Update
Wet Contact, ON Voltage Level	5 ~ 15 V (Max 24 V)
Wet Contact, OFF Voltage Level	0 ~ 1 V
Dry Contact, ON Voltage Level	Close to GND
Dry Contact, OFF Voltage Level	Open
Isolation	3750 Vrms (Using external power)

PC Bus
Type	PCI Express x 1
Data Bus	8-bit

Power
Consumption	600 mA @ +3.3 V 400 mA @ +12 V

Mechanical
Dimensions (mm)	105 x 180 x 22 (W x L x D)

Environmental
Operating Temperature	0 ~ +60°C
Storage Temperature	-20 ~ +70°C
Humidity	5 ~ 85% RH, Non-condensing

Download

Manual

Data sheet

Odering information

PEX-P64 CR

PCI Express, 64-ch Optically Isolated Digital Input Board (RoHS)
Includes one CA-4037B cable and two CA-4002 D-Sub connectors
