Card ISA 8 kênh AO + 16 kênh DI/DO + 3 kênh Timer/Counter/Frequency ICP DAS ISO-DA8 CR

Thương hiệu: ICP DAS | Tình trạng: Còn hàng

Liên hệ

ISA Bus, 8-ch, 14-bit Isolated AO Board

THÔNG TIN SẢN PHẨM

Features

Built-in DC/DC converter with 3000 VDC isolation
ISA bus
2500 VDC photo-isolation protection
8-channel, 14-bit analog output
Voltage/current outputs from each converter
Output Type ( Unipolar or Bipolar ) and output range ( 0 ~ 5 V, +/-5 V, 0 ~ 10 V, +/-10 V) can be software programmable
4 ~ 20 mA current sink to ground from each converter
Double-buffered D/A latch
Command set programming
Software Calibration

Introduction

The ISO-DA8 is bus-type isolated 14-bit D/A card for PC/AT compatible computers. The optical isolation of the ISO-DA8 can operate with up to 2500 VDC of common-mode voltage. The ISO-DA8 offers 8-channel double-buffered analog output. The output range may be configured from these ranges : +/-10 V, +/-5 V, 0~10 V, 0~ 5 V voltages output or 4 ~ 20 mA or 0 ~ 20 mA current loops sink. The board*s innovative design improve several drawbacks of the conventional isolated D/A card . For example : 1. Jumperless,Trimless 2. The power-on value of analog output can be pre-defined by the user and stored in the on board EEPROM 3. High channel count output can be designed implemented in half size. 4. The calibration is performed under software control, thus eliminating manual trimpot adjustments. The calibration data is stored in EEPROM. Easy recalibration ensures the accuracy of the board.

Specification

Hardware
Connector	Female DB37 x 1 20-pin Box header x 2

Analog Output
Channels	8
Range	Voltage: ±10 V Current: 0 ~ 20 mA
Resolution	14-bit
Accuracy	0.04% of FSR ±2 LSB @ 25 °C, ± 10 V
Voltage Output Capability	±5 mA
Response Time	250 kHz (Typical)
Slew Rate	0.6 V/μs
Operation Mode	Static Update

Digital Input
Channels	16
Type	5 V/TTL
TTL Input, ON Voltage Level	2.0 V Min.
TTL Input, OFF Voltage Level	0.8 V Max.
Response Speed	1.0 MHz (Typical)
Trigger Mode	Static Update

Digital Output
Channels	16
Type	5 V/TTL
Operation Mode	Static Update
Voltage	Logic 0: 0.4 V Max. Logic 1: 2.4 V Min.
Max. Load Current	Sink: 2.4 mA @ 0.8 V Source: 0.8 mA @ 2.0 V
Response Speed	1.0 MHz (Typical)

Timer/Counter/Frequency
Channels	3
Type	5 V/TTL
Resolution	16-bit
Reference Clock	Internal: 4 MHz

PC Bus
Type	ISA
Data Bus	8-bit

Power
Consumption	800 mA @ +5 V

Mechanical
Dimensions (mm)	122 x 182 x 22 (W x L x D)

Environmental
Operating Temperature	0 ~ +60°C
Storage Temperature	-20 ~ +70°C
Humidity	5 ~ 85% RH, Non-condensing

Download

Data sheet

D ocuments

Odering information

ISO-DA8 CR

ISA Bus, 8-ch, 14-bit Isolated Analog Output Board (RoHS)
Includes one CA-4002 D-Sub connector
