Miễn phí vận chuyển với đơn hàng từ 10.000.000đCard PCI Express 16 kênh đầu vào số DI + 16 kênh đầu ra PhotoMos Relay ICP DAS PEX-P16POR16i CR
Features
Introduction
The PEX-P16POR16i is a PCI Express card. These cards provide 16 optically isolated input channels and 16 PhotoMOS Relay output channels. Both the isolated DI channels and the PhotoMOS Relay channels use a short optical transmission path to transfer an electronic signal between elements of a circuit and keep them electrically isolated. The PEX-P16POR16i card provide 2000 VDC for DI channel isolation protection, allowing the input signals to be completely floated so as to cut down ground loops, block voltage spikes, and isolate the host computer from damaging voltages. PhotoMOS Relays are used where it is necessary to control a circuit using a low-power signal (with complete electrical isolation between the control and controlled circuits), or where several circuits must be controlled by one signal. These cards can be used in various applications, such as controlling the ON/OFF state of external devices, driving external relays or small power switches, activating alarms, contact closure, sensing external voltages or switches, etc.
The PEX-P16POR16i card also adds a Card ID switch on-board. Users can set Card ID and then recognizes the board by the ID via software when using two or more cards in one computer.
The cards support various OS versions, such as Linux, DOS, Windows. DLL and Active X control together with various language sample program based on Turbo C++, Borland C++, Microsoft C++, Visual C++, Borland Delphi, Borland C++ Builder, Visual Basic, C#.NET, Visual Basic.NET and LabVIEW are provided in order to help users to quickly and easily develop their own applications.
Specification
| Hardware | |
|---|---|
| Card ID | Yes (4-bit) |
| Connector | Female DB37 x 1 40-pin box header x 1 |
| Digital Input | |
|---|---|
| Channels | 16 |
| Type | Photocoupler (Sink and Source) |
| Response Speed | Without Filter: 50 kHz (Typical) With Filter: 0.455 kHz(Typical) |
| Trigger Mode | Static Update |
| Wet Contact, ON Voltage Level | AC/DC 5 ~ 24 V (AC 50 ~ 1 kHz) |
| Wet Contact, OFF Voltage Level | AC/DC 0 ~ 1 V |
| Isolation | 2000 VDC |
| Relay Output | |
|---|---|
| Channels | 16 |
| Type | PhotoMos Relay (Form A) |
| Contact Rating | Load Voltage: 300 V (AC peak or DC) Load Current: 130 mA |
| Operate Time | 0.7 ms (Typical) |
| Release Time | 0.05 ms (Typical) |
| Electrical Endurance | Long Life and No Sparking |
| PC Bus | |
|---|---|
| Type | PCI Express x 1 |
| Data Bus | 16-bit |
| Power | |
|---|---|
| Consumption | 600 mA @ +3.3 V 300 mA @ +12 V |
| Mechanical | |
|---|---|
| Dimensions (mm) | 113 x 118 x 22 (W x L x D) |
| Environmental | |
|---|---|
| Operating Temperature | 0 ~ +60°C |
| Storage Temperature | -20 ~ +70°C |
| Humidity | 5 ~ 85% RH, Non-condensing |
Download
Odering information
| PEX-P16POR16i CR | PCI Express x1, 16-channel isolated digital input and 16-channel PhotoMOS Relay output (RoHS) Includes one CA-4037W cable and two CA-4002 D-Sub connectors |
