Miễn phí vận chuyển với đơn hàng từ 10.000.000đModule Profibus Slave 8 kênh đầu vào tương tự AI ( Cặp nhiệt Thermocouple) ICP DAS PROFI-5018/S CR
Features
• Protocol & Hierarchy : DP-V0 Slave
• Supports PROFIBUS Transmission Rate (kbps) : 9.6, 19.2, 45.45, 93.75, 187.5, 500, 1500, 3000, 6000, 12000
• Transmission Rate Setting : detected automatically
• Address Setting : Address 0~126 set by rotary switches or SSA Telegram
• Indicators : PWR LED, RUN LED, ERR LED
• I/O modules Configuration : Configured by GSD file
• Network Isolation Protection : High Speed iCoupler
• 4KV ESD Protection : Contact for each terminal
Introduction
The PROFI-5018 is specially designed for the slave device of PROFIBUS DP protocol. It supports up to 10-channel Thermocouple Input Module with High Voltage Protection. Users can easily to choose and configure it by using the GSD file in any PROFIBUS Configurator.
Specifications
| CPU Module | |
|---|---|
| CPU | 80186, 80 MHz or compatible |
| EEPROM | 2 KB |
| Flash | 512 KB |
| SRAM | 512 KB |
| Watchdog Timer | Watchdog IC CPU built-in |
| LED Indicators | |
|---|---|
| Status | PWR LED, RUN LED, ERR LED |
| Analog Input | |
|---|---|
| Channels | 10 channel differential thermocouple input, Isolation Voltage:2500Vrms |
| Range | +/-15mV, +/-50mV, +/-100mV, +/-500mV, +/-1V, +/-2.5V, +/-20mA, 0~20mA, 4~20mA (requires optional external 125 Ohms resistor), Thermocouple Type: J, K, T, E, R, S, B, N, C |
| Accuracy | +/- 0.1 of FSR |
| PROFIBUS | |
|---|---|
| Controller | Siemens SPC3 |
| Transceiver | DI ADM2486 |
| Baud Rate | 9.6 k, 19.2 k, 45.45 k, 93.75 k, 187.5 k, 500 k, 1.5 M, 3 M, 6 M, 12 M |
| Isolation | 3000 VDC for DC-to-DC, 2500 Vrms for bus-to-logic |
| Protocol | DP-V0 |
| Power | |
|---|---|
| Consumption | 3.5 W |
| Mechanical | |
|---|---|
| Dimensions (mm) | 91 x 130 x 52 (W x L x H) |
| Installation | DIN-Rail |
| Environmental | |
|---|---|
| Operating Temperature | -25 ~ +75℃ |
| Storage Temperature | -30 ~ +80 ℃ |
| Humidity | 10 ~ 90% RH, Non-condensing |
Download
Ordering information
| PROFI-5018/S CR | PROFIBUS Remote I/O Module (10-channel Thermocouple Input with High Voltage Protection) (RoHS) Includes a DB-1820 daughter board |
