Modem 5G công nghiệp USB ICP DAS GTM-205M-5GE CR

Thương hiệu: ICP DAS | Tình trạng: Còn hàng

Liên hệ

Industrial 5G Modem with USB 3.1 Super Speed Plus interface.(Asia Only, Except China)

THÔNG TIN SẢN PHẨM

Feature

Support 5G SA/NSA Bands
Support 4G/3G Global Bands
Support TCP Server, TCP Client, and UDP Client Connection from 5G/4G
Support Standard AT Commands
Includes a Digital Input Channel to reset the System
Supports USB 3.1 Super Speed Plus Interface.
DIN-Rail mountable

Introduction

The GTM-205M-5G is an industrial 5G NR modem with USB Super Speed Plus interfaces that work at frequencies of 5G NR n1/n2/n3/n5/n7/n8/n12/n20/n28/n41/n66/n71/n77/n78/n79 and LTE Global Bands and WCDMA B1/B2/B3/B4/B5/B6/B8/B19. The modems utilize the 5G, 4G or 3G network to transfer data. The features of the GTM-205M-5G allow a variety of PAC and PC applications to take advantage of SMS and 5G or 4G or 3G connectivity.

Application

Specifications

LED Indicators
Status	1 x Power 1 x 5G

3G System
Frequency Band	B1/B2/B3/B4/B5/B6/B8/B19

4G System
Data Transmission Rate	FDD: B1/B2/B3/B4/B5/B7/B8/B12(B17)/B13/B14/B18/B19/B20/B25/B26/B28/B29/ B30/B32/B66/B71 TDD: B34/B38/B39/B40/B41/B42/B48

5G System
Frequency Band	n1/n2/n3/n5/n7/n8/n12/n20/n28/n41/n66/n71/n77/n78/n79

Reset Input
Type	Isolated, 3750 Vrms
ON Voltage Level	+3.5 VDC ~ +30 VDC
OFF Voltage Level	+1 VDC max.T40
Input Impedance	3 kΩ, 0.25W

COM Ports
Ports	1 x RS-232 (RxD, TxD, GND. Only for software reset system.)
Baud Rate	115200 bps

USB
Specification	USB 3.1 (Super speed plus)
Driver	Windows 10_x64、Windows 11

Mechanical
Casing	Metal
Dimensions (mm)	28 x 78.5 x 100 (W x L x H)
Installation	DIN-Rail

Environment
Operating Temperature	-25℃ to 70℃
Storage Temperature	-40℃ to 80℃
Humidity	5~90% RH, non-condensing

Download

Datasheet

Documents

Ordering Information

GTM-205M-5GE CR

Industrial 5G Modem with USB 3.1 Super Speed Plus interface. (RoHS) (Asia Only, Except China)
