Card PCI 64 kênh ra số DO ICP DAS PISO-A64U CR

Thương hiệu: ICP DAS | Tình trạng: Còn hàng

Liên hệ

Universal PCI, 64-ch Open Collector Isolated (Source, PNP) DO Board

THÔNG TIN SẢN PHẨM

Features

Support the +3.3/+5 V PCI bus
Card ID Function(SMD Switch)
Digital Output status readback
64 optically isolated DO (open collector) channels
Four isolated banks when using four isolated external power supplies
3750 Vrms photo-isolation protection

Introduction

The PISO-A64U universal PCI card supports 3.3 V/5 V PCI bus. These cards provide 64 optically isolated digital output channels, each of which offers a PNP transistor and an integrated suppression diode for the inductive load. The isolated DO channels use a short optical transmission path to transfer an electronic signal between the elements of a circuit and keep them electrically isolated. The open collector outputs (DO channels) are typically used for alarm and warning notification, signal output control, control for external circuits that require a higher voltage level, and signal transmission applications, etc. The board acts as an interface to field logic signals, eliminates ground-loop problems, and isolates the host computer from damaging voltages. These cards have a DB-37 connector and a 40-pin male header, each of which contains 32 output channels.

The PISO-A64U also adds a Card ID switch on-board. Users can set Card ID and then recognizes the board by the ID via software when using two or more PISO-A64U cards in one computer.

The cards support various OS versions, such as Linux, DOS, Windows. DLL and Active X control together with various language sample program based on Turbo C++, Borland C++, Microsoft C++, Visual C++, Borland Delphi, Borland C++ Builder, Visual Basic, C#.NET, Visual Basic.NET and LabVIEW are provided in order to help users to quickly and easily develop their own applications.

Accessories

Specification

Hardware
Card ID	Yes (4-bit)
Connector	Female DB37 x 1 40-pin Box header x 1

Digital Output
Channels	64
Type	Source(PNP), Open Emitter
Operation Mode	Static Update
Max. Load Current	100 mA/+30 V for each channel @ 60% duty
Response Speed	4 kHz (Typical)
Isolation	3750 Vrms

PC Bus
Type	3.3 V/5 V Universal PCI, 32-bit, 33 MHz
Data Bus	8-bit

Power
Consumption	800 mA @ +5 V

Mechanical
Dimensions (mm)	105 x 180 x 22 (W x L x D)

Environmental
Operating Temperature	0 ~ +60°C
Storage Temperature	-20 ~ +70°C
Humidity	5 ~ 85% RH, Non-condensing

Download

Data sheet

D ocuments

Odering information

PISO-A64U CR

Universal PCI, 64-ch Open Collector Isolated Digital Output Board (Current Sourcing, PNP)
Includes one CA-4037B cable and two CA-4002 D-Sub connectors
